Product Description

IFace 302 multi-biometric identification time attendance and access control terminal adopts latest Face 7.0 algorithm and large capacity memory. I Face series integrated 630MHz high speed Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of I Face are designed to be performed on the 4.3 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional Wi-Fi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure.

Technical Specification

• Dimension(WxHxD): 193.6 X 147.6 X 111 mm
• Face Capacity: 400 (1:N) /700(1:G) /3000(1:1)
• ID Card Capacity: 10,000
• Fingerprint Capacity:3,000
• Transaction Storage : 1,00,000
• Camera : High Resolution Infrared Camera
• Communications: RS232 ,RS485, TCP/IP
• USB-HOST: Two USB-Host
• Processor: Multi-Bio CPU 630 MHz
• Memory : 256M Flash, 64M SDRAM
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Acess Control Interface: 3rd party Electric lock, Door Sensor, Exit button
• Power Supply: 12V DC ,3A
• Access Attendance Standard Function: ID Card(302 optional) ,Automatic Status Switch
• Optional Function: Mifare Card , Short MAssage ,WebServer ,GPRS ,Batrry Back (200 mA) ,9 Digit User ,Work Code
• Wigand Signal: Output
• Alogrithm Version: Face 7.0
• Display : 4.3 Inch TFT Screen
• Gross Weight : 1.8 Kg
• Language: English

Product Description

IFace 202 multi-biometric identification time attendance and access control terminal adopts latest Face 7.0 algorithm and large capacity memory. I Face series integrated 630MHz high speed Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of I Face are designed to be performed on the 4.3 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional Wi-Fi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure

Technical Specification

• Dimension(WxHxD): 193.6 X 147.6 X 101 mm
• Face Capacity: 400 (1:N) /700(1:G) /3000(1:1)
• Fingerprint Capacity: 2000
• ID Card Capacity: 10,000
• Transaction Storage : 1,00,000
• Camera : High Resolution Infrared Camera
• Communications: RS232 ,RS485, TCP/IP
• USB-HOST: Two USB-Host
• Processor: Multi-Bio CPU 630 MHz
• Hardware Platfor : 600 Multi-Medium Development Platfrom
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Fingerprint Sensor: Optical Fingerprint Sensor without film
• Acess Control Interface: 3rd party Electric lock, Door Sensor, Exit button
• Power Supply: 12V DC ,3A
• Access Attendance Standard Function: ID Card ,Automatic Status Switch ,Self-Service ,T9 Input
• Optional Function: Mifare Card ,Short MAssage ,WebServer ,GPRS ,Batrry Back (200 mA) ,Work Code ,DLST ,9 Digit User
• Wigand Signal: Output
• Alogrithm Version: Face 7.0
• Display : 4.3 Inch TFT Screen
• Gross Weight : 1.8 Kg
• Language: English

Product Description

IFace 101 multi-biometric identification time attendance terminal adopts latest Face 7.0 algorithm and large capacity memory .I Face series integrated 630MHz high speed Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of I Face are designed to be performed on the 2.0 inches TFT screen with keypad operation. Multi-model communications includes RS232/485, TCP/IP, optional Wi-Fi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure

Technical Specification

• Dimension(WxHxD): 193.6 X 147.6 X 101 cm
• Face Capacity: 400 (1:N) /700(1:G) ,1500/3000(1:1) optional
• ID Card Capacity: 10,000
• Transaction Storage : 1,00,000
• Camera : High Resolution Infrared Camera
• Communications: RS232 ,RS485, TCP/IP ,USB
• Processor: Multi-Bio CPU 630 MHz
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Power Supply: 12V DC ,3A
• Optional Function: Mifare Card ,Short MAssage ,WebServer ,WiFi ,GPRS ,9 Digit User ,Work Code
• Alogrithm Version: Face 7.0
• Display : 2.0 Inch TFT Screen
• Gross Weight : 1.5 Kg
• Language: English

Product Description

SC203 is a RFID  Time and Attendance Systems, with Access Control. Its a  low priced device with good performance, designed especially in the purpose of popularizing the fingerprint products. It could store 30000 cards and 50000 transaction records.

Technical Specification

• Dimension(WxHxD): 19.0 X 14.5 X 3.5 cm
• User Capacity: 30,000
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP ,USB
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Card reader: EM RFID(Proximity), Mifare(optional) ,HID (optional)
• Power Supply: 12V 2Amp
• Wiegand Signal : Output & Input
• Standard Function: Anti-PassBack
• Access Control Interface : 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Optional Function: Mifare , HID ,Work Code ,Webserver
• Dispaly: LCD Screen
• Gross Weight : 0.8 Kg
• Language: English

Product Description

I clock is a standalone fingerprint T&A + Access Control system. I CLock 990 is a high end machine with lot of features. It could be accessed from any where in the world via Webpased software. It could store 10,000 fingerprint templates and 1,00,0000 transaction records.

Technical Specification

• Dimension(WxHxD): 21.5 X 14.5 X 3.5 cm
• User Capacity:2,200
• Transaction Storage : 1,00,000
• Communications: RS232 ,RS485, TCP/IP ,USB
• Processor: 32 Bit
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Card reader: EM RFID(Proximity), Mifare(optional) ,HID (optional)
• Acess Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC ,400mA
• Standard Function: Work code ,DLST ,Anti-Pass Back
• Optional Function: WebServer ,WiFi ,GPRS ,CDMA
• Wigand Signal: Input & Output
• Alogrithm Version: Finger v9.0
• Dispaly: 3 Inch LCD TFT
• Language: English

Product Description

FBAC 9090 is a standalone fingerprint T&A + Access Control system. It could store 2,200 fingerprint templates and 50,000 transaction records.

Technical Specification

• Dimension(WxHxD): 90 X 190 X 39.5 mm
• User Capacity:2,200
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Acess Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC
• Standard Function: 9 digit user ID
• Wigand Signal: Output
• Alogrithm Version: Finger v9.0
• Dispaly: Black & White LCD Screen
• Gross Weight: 0.7 Kg
• Language: English

Product Description

FBAC 0909 is a standalone fingerprint T&A + Access Control system. It could store 2,200 fingerprint templates and 50,000 transaction records.

Technical Specification

• Dimension(WxHxD): 90 X 190 X 39.5 mm
• User Capacity:2,200
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Access Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC
• Standard Function: 9 digit user ID
• Wigand Signal: Output
• Alogrithm Version: Finger v9.0
• Dispaly: Black & White LCD Screen
• Gross Weight: 0.7 Kg
• Language: English

Product Description

SC403 is a RFID Time and Attendance Systems, IN and OUT status, also low price with good performance, designed especially in the purpose of popularizing the fingerprint products. It could store 30,000 cards and 50,000 transaction records. It will bring you much profits because of its low price.

Technical Specification

• Dimension(WxHxD): 19.0 X 13.5 X 3.6 cm
• User Capacity: 30,000
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP ,USB-Host
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Card reader: EM RFID(Proximity), Mifare(optional) ,HID (optional)
• Power Supply: 12V 2A
• Wiegand Signal : Output & Input
• Standard Function: Anti-PassBack
• Optional Function: Mifare , HID ,Work Code ,Webserver
• Dispaly :  LCD Screen
• Gross Weight : 0.8 Kg
• Language: English

Product Description

FBAC 2727is a standalone fingerprint T&A + Access Control system. It could store 2,200 fingerprint templates and 50,000 transaction records.

Technical Specification

• Dimension(WxHxD): 90 X 190 X 39.5 mm
• User Capacity:2,200
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Access Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC
• Standard Function: Work code ,DLST
• Optional Function: 9 Digit User ID
• Wigand Signal: Output
• Alogrithm Version: Finger v9.0
• Dispaly: Black & White LCD Screen
• Gross Weight: 0.7 Kg
• Language: English

Product Description

X990 is a standalone fingerprint T&A + Access Control system with IN and OUT status. It could store 3,000 fingerprint templates and 1,00,0000 transaction records. It could be used for door control purposes. Can connect exit Fingerprint/ RF Card reader via Wiegand port. It is having multiple alarm clock options.

Technical Specification

• Dimension(WxHxD): 21.5 X 14.5 X 3.5 cm
• User Capacity:3,000
• Transaction Storage : 1,00,000
• Communications: RS232 ,RS485, TCP/IP ,USB
• Processor: 32 Bit
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Card reader: EM RFID(Proximity), Mifare(optional) ,HID (optional)
• Acess Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC ,400mA
• Standard Function: Work code ,DLST ,Anti-Pass Back
• Optional Function: WebServer ,WiFi ,GPRS ,CDMA ,Battery Backup
• Wigand Signal: Input & Output
• Alogrithm Version: Finger v9.0/10.0
• Dispaly: 3 Inch LCD TFT
• Language: English

Product Description

201 HE is proximity based RFID Access Control Systems without communication,low price with good performance, designed especially for access control for high security zone, Server room, Datacenter etc.  Supports 3 opening way: card, pin, card+pin. With relay output can control the lock.

Technical Specification

• No.of Users : 1000
• Working Frequency 125KHZ/13.56MHZ
• Size: 87.5 X 109 X 33 mm
• Read Range: Upto 10 cm
• Reading Time (card): <=300ms
• Weight:150g
• Power : 12 V DC/Max 70mA
• Output Ports: External Lock Control, External Buzzer Control
• Support Exit Switch
• LED Indicator: 2 Color LED Indicators(Red and Green)
• Beeper : Yes
• Temperature : 0°C – 45°C
• Operating Humidity : 20%- 80%

Product Description

F8 is a standalone fingerprint T&A + Access Control system with a strong enclosure. It could store 2,200 fingerprint templates and 50,000 transaction records.

Technical Specification

• Dimension(WxHxD): 100 X 196 X 53.5 mm
• User Capacity:2,200
• Transaction Storage :50,000
• Communications: RS232 ,RS485, TCP/IP ,USB
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Card reader: EM RFID(Proximity), Mifare ,HID (optional)
• Access Control Interface: 3rd party electric lock, door sensor, exit button, alarm, Door Bell
• Power Supply: 12V DC
• Standard Function: Work code ,DLST ,9 digit user ID
• Wigand Signal: Input & Output
• Alogrithm Version: Finger v9.0
• Dispaly: Black & White LCD Screen
• Gross Weight: 1.10 Kg
• Language: English

Product Description

KR 100HE (125KHz) is proximity based RFID Door Exit reader with Wiegand communication to connect to a master Access Control Device. Designed especially for access control for high security zones, Server room ,Datacenter etc.

Technical Specification

• Size: 116 X 75 X 17.3 mm
• Read Range: Upto 10 cm
• Reading Time (card): <= 300ms
• Weight:120g
• Power : DC 6-14/Max 70mA
• Input Port: 2ea (External LED Control, External Buzzer Control)
• Card Output: Weigand 26 Bit
• LED Indicator: 2 Color LED Indicators(Red and Green)
• Beeper : Yes
• Temperature : 0°C – 45°C
• Operating Humidity : 20%- 80%

KR100M-Exit card reader is a type of standard Wigand 26bits output format, non-contact high performance inductive card reader. It is mainly used as supporting card reading device for the access controller with Wigand interface and its characteristics are smart and exquisite appearance, simple wiring and stable performance

• Size: 116 X 75 X 17.3 mm
• Read Range: Upto 5 cm
• Reading Time (card): <= 300ms
• Weight:120g
• Power : DC 6-14/Max 70mA
• Input Port: 2ea (External LED Control, External Buzzer Control)
• Card Output: Weigand 26 Bit
• LED Indicator: 2 Color LED Indicators(Red and Green)
• Beeper : Yes
• Temperature : 0°C – 45°C
• Operating Humidity : 20%- 80%

Product Description

SR100 is a Fingerprint Exit Sensor. It acts as a slave reader.Its compatible with Access Control Device F8

Technical Specification

• Dimension(WxHxD): 12.9 X 7 X 3.5 cm
• Communications: Acts as Slave Reader
• Identification time : < =2S
• FAR: <=0.0001%
• FRR: <=1% Operating
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Sensor: OEM Optical Sensor 500 DPI
• Supporting Devices: FBAC 702 ,FBAC 9 ,F8

Product Description

The Fingerprint lock offers state-of-the-art single door management solution that provides you with unmatched options that comes with OLED, standard USB interface. You can verify a person and open the door with fingerprint, password and ID/Mifare cards. The All-in-one fingerprint lock is very convenient to operate. Enrollment and management of users are done on the OLED display. There are three user levels available to manage the system effectively-administrator, supervisor and user. An administrator or supervisor can do add, delete or change users very easily at the lock. The USB Port for data transmission is the main feature of the lock which makes it easy to download user Transaction from the lock-Professional and Intelligent.

Technical Specification

• Dimension(LxWxH): 315 X 78 X 88 mm
• Lead Indicator: Green & Red
• Storage
• Fingerprint Templates : 500
• Password : 100
• Event Capacity : 30,000
• Length of pAssword : 6 to 10 digit
• Cad : Proximity : 125 KHz (optional)
• Mifare : 13.56 MHz (optional)
• Front Panel Colors : Black
• Material : Zinc Alloy/Stainless steel finish
• Fingerprint Sensor: Optical Sensor 500 DPI
• Method : Fingerprint (1:1, 1:N), Password & Card
• Communication Model : USB flash disk
• Type Of Card : 13.56 MHz Mifare
• Temperature : 0°C – 45°C
• Operating Humidity : 20%-80%
• Low battery warning voltage : < 4.8 V
• Power input : 4 x 1.5V AA Battery
• Backup Unlock Mechanism : Emergency battery & Mechanical key
• Language: English

Product Description

essl no touch exit sensor with unique design with LED indicators shall suit for high profile companies. This sensor uses contactless technologies for door release.

Technical Specification

• Contact Rating : 3 A/AC 120 V, Dc 30 V
• Life : 5,00,000 lbs
• Temperature : 20°C – 55°C
• Weight : 85 g
• Optional Accessories : Gate ,Door ,Exit ,Automation Control

Product Description

essl HC2306F EM lock is capable of holding doors weighing up to 600lbs it also comes with indication device to monitor the status of the premises, whether it is opened or closed.

Technical Specification

• Magnet(L X W X H ): 250 X 41 X 26 mm
• Armature Plate(L X W X H ): 180 X 38 X 11 mm
• Mounting Plate(L X W X H ): 250 X 25.4 X 6.3 mm
• Current Consumption : 500mA/250mA
• Voltage: 12 V/24 V
• Voltage Tolerance : 115%
• Holding Force : 230 Kg
• Holding Capacity : 600 lbs
• Temperature : 10°C – 55°C
• LED MAgneticbondsensor
• Optional Accessories : L Bracket ,U Bracket ,ZL Bracket ,U Bracket for Glass Door

Product Description

We offer many types door release, such as Plastic door release, Stainless steel push button, Plastic Button and exit button.Panel with strongly style, applicable to hollow door. Stainless steel panel with strongly style, applicable to hollow door

Technical Specification

• Max Current : 3A/36 VDC(No/NC) output
• Size (L X W): 91 X 28 mm

Product Description

ZL mounting brackets are used to mount EM locks & Strike Plate to door frames and door panes.

ZL Brackets are made out of Aluminium.

Product Description

This is Wired Security Electric Door Lock for Frameless Glass, lock with electricity, magnetic induction, ball to fit position, low consumption, noiseless. Power to lock with signal output.

Technical Specification

• Base Size(L X W X H ): 5.83 X 1.69 X 0.98 Inch
• Body Size(L X W X H ): 5.74 X 0.96 X 1.54 Inch
• Mounting Plate(L X W X H ): 250 X 25.4 X 6.3 mm
• Bolt Size : 0.49 diameter Inch
• Lock Delay : 0 ~ 6 Seconds adjustable
• Current : starting Current 1.3 A
• Working Voltage: DC 12 V
• Red Side : Positive electrode
• Black Side : Negative electrode
• Temperature : 10°C – 55°C
• Operating Humidity : 0%-95%
